10/100/1000M Single Fiber Optic Transceivers Media Converter
10/100/1000M Ethernet media converter adopts switching technology to fulfill media conversion.
It complies with IEEE802.3z and IEEE802.3ab standards, and supports two types of media network
connections: 10/100/1000Base-T and 1000Base-SX/LX.
It inter-converts electrical signals of 10/100/1000Base-T twisted pairs with optical signals of 1000Base-SX.
It extends the network transmission distance from 100m to 80km via fiber optical cable.
It supports transmission in multi-mode single fiber; single-mode single fiber.
Features
Ø Supporting inter-conversion between 10/100/1000Base-TX and 1000Base-SX
Ø Supporting full-duplex and half-duplex and its auto-sensed
Ø Supporting automatic cross connection of twisted pair interfaces,
facilitating system commissioning and installation.
Ø Supporting the transmission of extra-long VLAN packets
Ø Supporting Quality of Service (QoS) and ensuring the transmission of VoIP packets;
Ø Supporting STP to form a redundant network
| Parameter | Specifications |
| Access mode | 10/100/1000Mbps Gigabit Ethernet |
| Standard | IEEE802.3ab 1000Base-T , IEEE802.3z 1000Base-SX/LX Gigabit thernet,IEEE802.1qVLAN,IEEE802.1p QoS,IEEE802.1d Spanning Tree |
| Wavelength | 1310/1550nm |
| Transmission distance | Multi-mode:2 km; single-mode:20km~80km; Category-5 twisted pair: 100m |
| Port | One RJ45 connector: connected to STP/UTP category-5 twisted pair One optical port: MM: SC/ST/FC (fiber size: 50,62.5/125µm) SM: SC/ST/FC (fiber size: 9/125µm) |
| Conversion means | Media conversion |
| Delay | <10us |
| BER | <10-9 |
| MTBF | 100,000 hours |
| LED | PWR (power supply), FX LINK (optical link action), TP LINK1000 (twisted pair link1000M), TP LINK100 (twisted pair link 100M), TP ACT (twisted pair packet forwarding) |
| Power | AC220 0.5A/DC-48 (built-in) |
| Power consumption | 5W |
| Operating temperature | -10~55ºC |
| Operating humidity | 5%~90% |
| Maintaining temperature | -40~70ºC |
| Maintaining humidity | 5% ~ 90% non-condensing |
| Dimensions | 26mm (H) * 70mm (W) * 94 mm (D) (external power supply) |
| 30mm (H) * 110mm (W) * 140 mm (D) (internal power supply) |
